Details And Data Sheet
Summary Table Of Hardware Configuration Of Aluminum Alloy Two-Way Rotating Door Lock Series Hardware System
Series No. | Material No. | Parts Name | Quantity | Remark |
1 | LHJSXMS-0800093 | Cross-handle | 1 | Optional |
2 | LHJSXMS-0800440 | Transmission lock box | 1 | Optional |
3 | LHJSXMS-0260120 | Side drive rod | 2 | |
4 | LHJSXMS-0260121 | Lock block | 2 | |
5 | LHJSXMS-0110121D | Two-hole button | 1 | |
6 | LHJSXMS-0110121C | Booster pad | 1 | |
7 | LHJSXMS-0110256L/R | Polish hinge | 3 |
Precautions:1. Customers can choose other types of handles from our company according to the introduction of the handle series in the product list window.2. Aluminum alloy profile that can be used for European-style groove cavity.3.The length of the square steel L = the thickness of the fan profile + 35 ~ 40mm, the length of the mounting screw (M5) L = the thickness of the fan profile + 15mm.
There are a variety of handles to choose from: square handle to pass through handle, round handle to pass through handle, to pass handle-with key
The factory manufacturer supplys the product,
which can save intermediate links,and gives the maximum profit to the consumers.
Our Advantages1. The raw materials of the castings are made of four-in-one zinc alloy, and the advanced material formula (±50 ℃) does not deform or break.2. All stainless steel parts are made of 304 material, containing 7.5-8.5 nickel, which does not rust.3. The plastic parts in the fitting system are made of high-strength wear-resistant nylon PA66 material, which will never be damaged.4. The spraying part is sprayed with polyurethane material, the thickness is 45μm-100μm, and the dry adhesion is more than 10 grades, all exceeding national standards5. The production equipment for zinc and aluminum die-casting machine is 120Ton, and the automatic punching machine is 180Ton,which ensure the hardness, strength and toughness of the casting. Inward opening, inverted, inner and outer casement windows open and close 450,000 times of opening and closing cycles, no distortion of parts, normal use6. The surface treatment of the plated parts is a trivalent chromium electroplating process, the thickness of the plating layer is 45μm-100μm, and the salt spray test is 120 hours without pinholes, bulging and rust.After nearly a year of repeated research and designing a mold opening test, Yuqiang Hardware has successfully improved the aluminum alloy casement window hinges, connectors, and inner opening and inverted hinge chains from the original aluminum alloy extrusion material to carbon steel. Stamping parts ensure that the load-bearing capacity of the accessories is increased. The original aluminum alloy hinges can load 70kg, and the carbon steel hinges can load up to 180kg without deformation or fracture.It has fundamentally solved the load-bearing problem of super-standard large windows and triple-glazed windows. Now this product has been declared a national patent, leading other domestic brands.Production ProcessBuying Procedures
Since its establishment, our factory has been developing first world class products with adhering the principle
of quality first. Our products have gained excellent reputation in the industry and valuabletrusty among new and old customers..
