ASTM A240 Type 304 Plate suppliers feom china
ASTM A240 Type 304 Plate suppliers feom china
Alloy 304/304L (UNS S30400/S30403) is the most widely utilized “18-8” chromium-nickel austenitic stainless steel. It is an economical and versatile corrosion resistant alloy suitable for a wide range of general purpose applications.
It is common practice for 304L to be dual certified as 304 and 304L. The low carbon chemistry of 304L combined with an addition of nitrogen enables 304L to meet the mechanical properties of 304.
Stainless Steel 304 Coil Density Chart
| Plate Type | Density |
| Stainless Steel 304 Plate | 8.0 g/cm3 |
304 Stainless Steel Strip Melting range
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 304/L/H | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
SME SA240 Stainless Steel 304 Plate Sizes
SS 304 Plate ThicknessSS 304 Plate SizeSS 304 Sheet Weight per Unit AreaEstimated Weight per Sheet
| 0.015 inches 0.381 mm | 36 x 96 | 0.630 lbs/ft²3.07566 kg/m² | 15.12 lbs6.84936 kg |
| 0.015 inches 0.381 mm | 36 x 120 | 0.630 lbs/ft²3.07566 kg/m² | 18.90 lbs8.5617 kg |
| 0.0178 inches 0.45212 mm | 36 x 96 | 0.756 lbs/ft²3.690792 kg/m² | 18.15 lbs8.22195 kg |
| 0.0178 inches 0.45212 mm | 36 x 120 | 0.756 lbs/ft²3.690792 kg/m² | 22.68 lbs10.27404 kg |
| 0.0178 inches 0.45212 mm | 48 x 96 | 0.756 lbs/ft²3.690792 kg/m² | 24.19 lbs10.95807 kg |
| 0.0178 inches 0.45212 mm | 48 x 120 | 0.756 lbs/ft²3.690792 kg/m² | 30.24 lbs13.69872 kg |
| 0.0235 inches 0.5969 mm | 30 x 96 | 1.008 lbs/ft²4.921056 kg/m² | 20.16 lbs9.13248 kg |
| 0.0235 inches 0.5969 mm | 30 x 120 | 1.008 lbs/ft²4.921056 kg/m² | 25.20 lbs11.4156 kg |
| 0.0235 inches 0.5969 mm | 36 x 96 | 1.008 lbs/ft²4.921056 kg/m² | 24.19 lbs10.95807 kg |
| 0.0235 inches 0.5969 mm | 36 x 120 | 1.008 lbs/ft²4.921056 kg/m² | 30.24 lbs13.69872 kg |
| 0.0235 inches 0.5969 mm | 36 x 144 | 1.008 lbs/ft²4.921056 kg/m² | 36.29 lbs16.43937 kg |
| 0.0235 inches 0.5969 mm | 48 x 96 | 1.008 lbs/ft²4.921056 kg/m² | 32.26 lbs14.61378 kg |
| 0.0235 inches 0.5969 mm | 48 x 120 | 1.008 lbs/ft²4.921056 kg/m² | 40.32 lbs18.26496 kg |
| 0.0235 inches 0.5969 mm | 48 x 144 | 1.008 lbs/ft²4.921056 kg/m² | 48.39 lbs21.92067 kg |
| 0.0291 inches 0.73914 mm | 30 x 96 | 1.260 lbs/ft²6.15132 kg/m² | 25.20 lbs11.4156 kg |
| 0.0291 inches 0.73914 mm | 30 x 120 | 1.260 lbs/ft²6.15132 kg/m² | 31.50 lbs14.2695 kg |
| 0.0291 inches 0.73914 mm | 36 x 96 | 1.260 lbs/ft²6.15132 kg/m² | 30.24 lbs13.69872 kg |
| 0.0291 inches 0.73914 mm | 36 x 120 | 1.260 lbs/ft²6.15132 kg/m² | 37.80 lbs17.1234 kg |
| 0.0291 inches 0.73914 mm | 36 x 144 | 1.260 lbs/ft²6.15132 kg/m² | 45.37 lbs20.55261 kg |
| 0.0291 inches 0.73914 mm | 48 x 96 | 1.260 lbs/ft²6.15132 kg/m² | 40.32 lbs18.26496 kg |
| 0.0291 inches 0.73914 mm | 48 x 120 | 1.260 lbs/ft²6.15132 kg/m² | 50.41 lbs22.83573 kg |
| 0.0291 inches 0.73914 mm | 48 x 144 | 1.260 lbs/ft²6.15132 kg/m² | 60.49 lbs27.40197 kg |
| 0.0355 inches 0.9017 mm | 30 x 96 | 1.512 lbs/ft²7.381584 kg/m² | 30.24 lbs13.69872 kg |
| 0.0355 inches 0.9017 mm | 30 x 120 | 1.512 lbs/ft²7.381584 kg/m² | 37.80 lbs17.1234 kg |
| 0.0355 inches 0.9017 mm | 36 x 96 | 1.512 lbs/ft²7.381584 kg/m² | 36.29 lbs16.43937 kg |
