Automatic Ampoule Forming Filling Sealing Machine

Short Description:


Product Detail

Product Tags

Application



This machine is suitable for the filling of unit doses of medicines, beverages, dairy products, health products, foods, cosmetics, perfumes, agricultural medicines, fruit pulps, nucleic acid testing, etc.

DGS-118 Ampoule Forming Filling & Sealing Machine is applicable for liquid, sticky, semi-sticky, and so on. This machine can be used for pharmaceuticals, food, health care products, cosmetics. It also can be used in industry and agriculture in similar products. This machine can finish forming, filling, sealing once time.

Features



1. Controlled by PLC, the frequency conversion in finely variable speeds.

2. All 6 processes from spreading roll, AMP bottle forming, filling, sealing the end, printing serial numbers, cutting the end, cutting apart, controlled by programming.

3. The computer human interface has a simple and clear operation.

4. The filling head does not drop, leak, rise in bubbles and spill over.

5. All are made of high-quality stainless steel, accord with the standard GMP.

6. Mostly pneumatic components and wirings adopt inward fittings.

7. Automatic and mechanical filling, precise calculation and limited deflection.

Technical Parameters

Model DGS-118P5
Max Forming Depth 16mm
Cutting Frequency 0-25 times/min
Packing Material PET/PE, PVC/PE
Packing Roll Two roll
Filling Volume 1-50ml
Filling Head 5 heads
Power 7kw
Voltage 220v-380v/50Hz
Size (L×W×H) 2300×850×1500(mm)
Weight 900Kg
