Brackish Water Purification Machine
Explanation
Brackish river/lake/underground/well water needs to be filtered and purified to make fresh pure water for drinking, showering, irrigation, home use, etc.
Quick Details
Place of Origin:China Brand Name:
Warranty:1 Year
Characteristic: customerized Production time: 90days
Certificate:ISO9001, ISO14001, OHSAS18001
Technical Data:
Capacity: 500m3/hr
Container: Frame mounted
Power consumption: 70kw.h
Recovery rate: 65%;
Raw water: TDS <15000ppm
Production water<800ppm
Operation method: Manual/Automatic
Process Flow
Brackish river/lake/underground/well → Raw water booster pump → Quartz sand filter → Activated carbon filter → Security filter → Precision filter → High pressure pump → RO system → Production water tank
Components
● RO membrane： DOW, Hydraunautics, GE
● Vessel：ROPV or First Line, FRP material
● HP pump：Danfoss super duplex steel
● Energy recovery unit：Danfoss super duplex steel or ERI
● Frame：carbon steel with epoxy primer paint, middle layer paint, and polyurethane surface finishing paint 250μm
● Pipe：Duplex steel pipe or stainless steel pipe and high pressure rubber pipe for high pressure side, UPVC pipe for low pressure side.
● Electrical： PLC of Siemens or ABB , electrical elements from Schneider.
Application
● Processing enterprises
● Municipal city drinking water plant
● Hotel/Resorts
● Industrial feeding water
● Gardening
Reference Parameters
|
Model |
Capacity ( t/d ) |
Working Pressure （MPa） |
Inlet Water Temperature （℃） |
Recovery （%） |
| JTRO-JS10 |
10 |
0.8-1.6 |
5-45 |
50 |
| JTRO-JS25 |
25 |
0.8-1.6 |
5-45 |
50 |
| JTRO-JS50 |
50 |
0.8-1.6 |
5-45 |
65 |
| JTRO- JS 100 |
100 |
0.8-1.6 |
5-45 |
70 |
| JTRO- JS 120 |
120 |
0.8-1.6 |
5-45 |
70 |
| JTRO- JS 250 |
250 |
0.8-1.6 |
5-45 |
70 |
| JTSO- JS 300 |
300 |
0.8-1.6 |
5-45 |
70 |
| JTRO- JS 500 |
500 |
0.8-1.6 |
5-45 |
70 |
| JTRO- JS 600 |
600 |
0.8-1.6 |
5-45 |
70 |
| JTRO- JS 1000 |
1000 |
0.8-1.6 |
5-45 |
70 |
