Model:86BLF
Wring Type————————————————Star
Hall Effect angle———————————————120°
Electrical angle Insulation——————————B
Temperature Range ———————————-20℃~+50℃
Insulation Resistance ——————————100MΩ Min.500V DC
DC Dielectric Strength ——————————500V AC 1minute
Model |
86BLF01 |
86BLF02 |
86BLF03 |
86BLF04 |
Number of poles |
8 |
|||
Number of phases |
3 |
|||
Rated Voltage VDC |
48 |
|||
Rated Speed RPM |
3000 |
|||
Hording torque N-m |
0.35 |
0.7 |
1.05 |
1.4 |
Output Power Watts |
110 |
220 |
330 |
440 |
Peak Torque N-m |
1.05 |
2.1 |
3.2 |
4.2 |
Peak Current Amps |
10.8 |
19.8 |
29.0 |
38.0 |
Rated Current Amps |
3.9 |
6.6 |
9.6 |
14 |
Line to line Inductance mH |
2.1 |
1.30 |
0.91 |
0.71 |
Torque Constant N-m/Amps |
0.11 |
0.11 |
0.11 |
0.11 |
Back EMF V/kRPM |
11.5 |
11.5 |
11.5 |
13.5 |
Rotor Ineria g·cm2 |
350 |
650 |
950 |
1250 |
Body Length mm |
57 |
67 |
81 |
94 |
Weight kg |
1.1 |
1.75 |
2.2 |
2.75 |
Mechanical Dimensio
Wiring Diagram
