Compactly YGX minisize hydraulic cylinders

Short Description:

Send email to us

Product Detail

Product Tags

Compactly YGX minisize hydraulic cylinders

The hydraulic actuators include that YGX series minisize hydraulic cylinders, LYG series hydraulic cylinders, the YG series hydraulic cylinders which was designed by Japanese JISB8354-1992 stan¬dard, FHSG series engineering hydraulic cylinders, CD series heavy hydraulic cylinders, Y —HG1 series metallurgical standard hydrau¬lic cylinders, special vehicle hydraulic cylinders and manufactured various non-standard hydraulic cylinders for clients* request.
The hydraulic systems include that hydraulic system assembly and the compositive equipments that we designed and manufactured basis on your working condition and request, such as pressure, flux and action request about.
We can manufacture various non-standard products and systems.
Applications and features of Compactly YGX minisize hydraulic cylinders.
The features of this product are advanced in capability, compact in structure, tiny in volume, beautiful in figure. It can be replaced with Japanese JIS series minisize hydraulic cylinders and has multiple utilizations.

Technical Parameter

Cylinder： bore inner20， outer32；
Working pressure ：7MPa；
The smallest start pressure ：03MPa；
Experiment pressure ：10.5Mpa；
Scope of using speed ：10~300mm/sec；
Standard stroke： 20,50,75,100,150,200；
Scope of stroke： 00300；
Scope of using temperature ：10c~80c；
Transmission medium： General mineral hydraulic oil.

The effective pressed areas of minisize hydraulic cylinder

Cylinder bore	The effective pressed areas of hydraulic cylinder (cm2)
Cylinder bore	Non- rod chamber	Rod chamber
①20	3.1	2.3
025	4.9	3.7
032	8.0	6.5

The model code of YGX minisize hydraulic cylinders
YGX /Cylinder bore /Stroke — Mounting mode —Connecting mode
ST /Standard type T/T type
LB /vertical to axis foot type Y/Y type
FA /Rod side flange type
CA / Rod single clevis type
TA / Trunnion type
Notes on ordering
1. Please specify the model and stroke when placing orders.
2. In addition to the hydraulic cylinders included in the catalogue, we can also design and manufacture the various non-standard hydraulic cylinders, Please contact us if you have any technical problem.

Specifications

Model	Nom. pressure (MPa)	Cylinder bore D(mm)	Speed ratio						Min. stroke of non-trunuion connection Sl(mm)
			1.33		1.46		2
			Rod dia. d (mm)	Max. stroke S (mm)	Rod dia. d (mm)	Max. stroke S (mm)	Rod dia. d (mm)	Max. stroke S (mm)
FHSGL01-40/dE		40	20	320	22	400	25	480
FHSGL01-50/dE		50	25	400	28	500	32	600
FHSGL01-63/dE		63	32	500	35	630	45	750
FHSGL01-80/dE		80	40	640	45	800	55	950
FHSGK01-80/dE		80	40	640	45	800	/	/	30
FHSGK01 — 90/dE		90	45	720	50	900	63	1080	40
FHSGK01-100/dE		100	50	800	55	1000	70	1200	40
FHSGK01 —110/dE		110	55	880	63	1100	80	1320	45
FHSGK01-125/dE	16	125	63	1000	70	1250	90	1500	35
FHSGK01 —140/dE		140	70	1120	80	1400	100	1680	50
FHSGK01-150/dE		150	75	1200	85	1500	105	1800	55
FHSGK01 —160/dE		160	80	1280	90	1600	110	1900	45
FHSGK01 — 180/dE		ISO	90	1450	100	1800	125	2150	45
FHSGK01-200/dE		200	100	1600	110	2000	140	2400	50
FHSGK01-220/dE		220	110	1760	125	2200	160	2640	50
FHSGK01-250/dE		250	125	2000	140	2500	180	3000	60

Mounting Dimensions

ST/ ST type

^J/Code	ST /ST type
^J/Code	A	B	C	D	E	F	G	H	J	K	L	M
020	25	35	16	51	79	138	8	ZG1/8^M	10	M8xl	29	M8xl
025	25	35	16	51	79	138	8	ZG1/8”	12	MlOxl.25	34	M10xl,25
032	30	40	18	58	82	148	8	ZG1/8”	14	M12xl.25	42	M12xl.25
