DPP-260 Automatic Flat Blister packing Machine

Short Description:

DPP-260 Automatic Blister packing Machine is our advanced equipment designed under updated improvement. Adopts of the integral technology applying frequency inverter for speed control and mechanism, electricity, light, and air to machine. Its design is in strict compliance with GMP standards and takes lead in the blister packer’s field. Featuring advanced functions, simple operation, high output, and the machine is ideal packing equipment for large and medium-size pharmaceutical enterprises, health food, and foodstuff plant.


Product Detail

Product Tags

DPH Series Roller Type High Speed Blister Packing Machine01

DPH Series Roller Type High Speed Blister Packing Machine02

Product Description

DPP-260 Automatic Blister packing Machine is our advanced equipment designed under updated improvement. Adopts of the integral technology applying frequency inverter for speed control and mechanism, electricity, light and air to machine. Its design is in strict compliance with GMP standard and takes lead in the blister packer’s filed. Featuring advanced functions, simple operation, high output, and the machine is ideal packing equipment for large and medium size pharmaceutical enterprises, health food and food stuff plant.

Technical Parameters

Max. Punch Speed

AL/PL: 40-60 times/min(stand type)

AL/AL: 20-40 times/min

Max. Production Capacity

AL/PL: 350 thous. /h

AL/AL: 150 thous. /h

Adjustable Range Of Stroke

Standard dispose≤120mm(according to the customers′ Requirement)

Max. Forming Area

245×112 mm

Max. Forming Depth

AL/PL: 14 mm

AL/AL: 14 mm

Specification Of Packaging Material

Note:The Width Of The Material 130-260mm

Medicine PVC: 260×0.25(0.15-0.5) mm

Heat-sealing PTP: 260×0.02 mm

Power Connection

There Phases Four Wires:
380V  50Hz  (220V 60Hz)

Total Power

6.4KW

Main Motor Power

2.2 KW

Forming Upper and Lower Heat power

1.5 KW(x2)

Heat-sealing Heat Power

1.2 KW

Air Pump(Air Compressor)Volume

≥0.38 m3/min

Dimensions Of Overall Machine(L×W×H)

3940x720x1580mm

Dimensions Of Packing Case(L×W×H)

4100x880x1740mm

Dimensions Of Separate Packing Cases(L×W×H)

2000x880x1740mm and 1550x880x1740

Weight

1800 kg
