FACE MASK FLOW WRAPPING MACHINE – SOONTRUE SZ180
| Model | SZ180 (Single Cutter) | SZ180 (Double Cutter) | SZ180 (Triple Cutter) |
| Bag Size: Length | 120-500mm | 60-350mm | 45-100mm |
| Width | 35-160mm | 35-160mm | 35-60mm |
| Height | 5-60mm | 5-60mm | 5-30mm |
| Packing Speed | 30-150bags/min | 30-300bags/min | 30-500bags/min |
| Film Width | 90-400mm | ||
| Power Supply | 220V 50Hz | ||
| Total Power | 5.0kW | 6.5kW | 5.8kW |
| Machine Weight | 400kg | ||
| Machine Size | 4000*930*1370mm | ||
1. Compact machine structure with smaller footprint area.
2. Carbon steel or stainless steel machine frame with nice appearance.
3. Optimized component design realizing fast and stable packing speed.
4. Servo control system with higher accuracy and flexibility mechanical motion.
5. Different optional configurations and functions meeting different specific requirements.
6. High accuracy of color mark tracking function.
7. Easy to use HMI with memory function.
Air exhausting device
This is optional items. Mainly use to remove the air in the bag. To achieve better packing effect.
Film loader
Top mounted film loader, with optional double film loader, auto centering and auto splicing. Optimized component design realizing fast and stable packing speed.
Bag former
Adjustable bag former with high flexibility for film width 90-370mm
End sealing assembly
Standard double cutter end sealing,with optional single cutter and triple cutters.
