High definition China Blince Mini Size Orbit Motor Omm Bmm 8cc 12.5cc 20cc 32cc 40cc 50cc
No matter new buyer or old purchaser, We believe in long expression and trusted relationship for High definition China Blince Mini Size Orbit Motor Omm Bmm 8cc 12.5cc 20cc 32cc 40cc 50cc, We glance forward to establish a long-term small business romance along with your esteem co-operation.
No matter new buyer or old purchaser, We believe in long expression and trusted relationship for BMS Orbit Motor, China Hydraulic Motor, Hydraulic Orbit Motor, Omm Hydraulic Motor, Orbit Motor, We’re sticking to excellent quality, competitive price and punctual delivery and better service, and sincerely hope to establish long-term good relationships and cooperation with our new and old business partners from all over the world. Sincerely welcome you to join us.
GENERAL INFORMATION
Cycloidal gear motors convert hydraulic energy (pressure, oil flow) into mechanical energy (torque, speed). Cycloidal gear motors operate on the principle of an internal gear (rotor) rotating within a fixed external gear (stator). The internal gear transmits the torque generated by the application of pressure from hydraulic oil fed into moto which is then delivered via the motor’s output shaft. Cycloidal gear motors have high starting torque and constant output torque at wide speed range.
DISTIBUTORVALVE
GR, GRS series motors have spool valve: the distributor valve has been integrated with the output shaft. The cardan shaft rotates distributor valve and transfers mechanical energy from gerotor set to output shaft. The valve has hydrodynamic bearings and has infinite life when load ratings are not exceeded.
GEAR WHEEL SET
There are two forms of gearwheel set:
Roll-gerotor set has teeth fitted with rollers. The rollers reduce local stress and the tangential reaction forces on the rotor reducing friction to a minimum. This gives long operating life and better efficiency even at continuous high pressures.
Roll-gerotor sets are recommended for operation with thin oil and for applications with continually reversing applications with continually reversing loads. GR, GRS series motors have roll-gerotor set.
APPLICATION
» Conveyors
» Feeding mechanism of robots and manipulators
» Metal working machines
» Textile machines
» Agricultural machines
» Food industries
» Grass cutting machinery etc.
OPTIONS
» Model-Spool valve, roll-gerotor
» Flange mount
» Motor with needle bearing
» Side and rear ports
» Shafts: straight, splined and tapered
» Shaft seal for high and low pressure
» Metric and BSPP ports
» Speed sensoring
» Other special features
GENERAL
| Max.Displacement | cm3/rev | 397 | ||
| Max.Speed | RPM | 970 | ||
| Max.Torque | Nm |
cont.:610 |
int.:690 | |
| Max.Output | KW | 15 | ||
| Max.Pressure Drop | Mpa |
cont.:17.5 |
int.:20 | |
| Max.Oil Flow | lpm | 75 | ||
| Min.Speed | RPM | 10 | ||
| Pressure Fluid | Mineral based-HLP(DIN 51524) or HM(ISO 6743/4) | |||
| Temperature Range | -40 to 140 | |||
| Optimal Viscosity Range | mm2/s | 20 to 75 | ||
| Filtration | ISO code 20/16 (Min.) (recommended fluid filtration of 25 microns) ISO 20/16 | |||
Specification data for GR series motor
| Displacement(cm3/rev) |
GR 50 |
GR 80 |
GR 100 |
GR 125 |
GR 160 |
GR 200 |
GR 250 |
GR 315 |
GR 400 |
|
|
51,5 |
80,3 |
99,8 |
125,7 |
159,6 |
199,8 |
250,1 |
315,7 |
397 |
||
| Max Speed | Cont. |
775 |
750 |
600 |
475 |
375 |
300 |
240 |
190 | 0 |
|
Int.* |
970 |
940 |
750 |
600 |
470 |
375 |
300 |
240 |
190 |
|
| Max Torque | Cont. |
100 |
200 |
240 |
300 |
390 |
385 |
390 |
360 |
380 |
| Nm | Int.* |
130 |
220 |
280 |
340 |
430 |
460 |
470 |
470 |
470 |
| Peak** |
170 |
270 |
320 |
370 |
460 |
560 |
600 |
610 |
610 |
|
| Max Output | Cont. |
7 |
12,5 |
13 |
12,5 |
11,5 |
9 |
8 |
5 |
4,8 |
|
Int.* |
8,5 |
15 |
15 |
14,5 |
14 |
12 |
9,5 |
8 |
6,8 |
|
| Max Pressure Drop | Cont. |
14 |
17,5 |
17,5 |
17,5 |
17,5 |
14 |
11 |
8,5 |
6,5 |
| Mpa | Int.* |
17,5 |
20 |
20 |
20 |
20 |
17,5 |
14 |
11,5 |
9 |
| Peak** |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
20 |
15 |
11,5 |
|
| Max Oil Flow | Cont. |
40 |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
|
Int.* |
50 |
75 |
75 |
75 |
75 |
75 |
75 |
75 |
75 |
|
| Max Inlet Pressure | Cont. |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
| Int.* |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
|
| Peak** |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
|
| Max.Return Pressure with Drain Line | Cont. |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
17,5 |
| Int.* |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
|
| Peak** |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
22,5 |
|
| Max.Starting Pressure with Unloaded Shaft |
1 |
1 |
1 |
0,9 |
0,7 |
0,5 |
0,4 |
0,3 |
0,3 |
|
| Min Starting Torque | At max.press. drop Cont. |
80 |
150 |
200 |
250 |
320 |
330 |
310 |
315 |
315 |
|
At max.press.drop Int.* |
100 |
170 |
230 |
280 |
370 |
400 |
480 |
580 |
500 |
|
| Min.Speed |
10 |
10 |
10 |
10 |
10 |
10 |
10 |
10 |
10 |
|
| Weight(kg) | MR(F) |
6,8 |
6,9 |
7,2 |
7,3 |
7,5 |
8 |
8,4 |
9,1 |
9,8 |
|
MRQ(N) |
6,2 |
6,3 |
6,6 |
6,8 |
7,6 |
7,2 |
7,8 |
8,6 |
9,3 |
|
