Split
Split actuators are suitable for high temperature, vibration, and occasions where installation space is limited or inconvenient to operate. Modbus communication is used between the electrical control part and the mechanical part, and the separation distance can be up to 150 meters.
Drive connection
The bottom connection size of the actuator conforms to the ISO 5210 standard. In addition to the standard hollow shaft with keyway, the shaft sleeve can also provide a three-jaw shaft sleeve and a T-thread sleeve that can withstand thrust.
The bottom connection size of the actuator and the type and specifications of the shaft sleeve can also be customized according to the needs of users.
body
The body is hard aluminum alloy, anodized and polyester powder coating, strong corrosion resistance, protection grade is IP67, NEMA4 and 6, and IP68 is available for selection.
Motor
Using a fully enclosed cage motor, it has the characteristics of small size, large torque, and small inertial force. The insulation grade is H grade, and the built-in overheating protection switch can prevent damage to the motor.
Manual structure
The design of the handwheel is safe, reliable, labor-saving and small in size. When the power is off, press the clutch for manual operation. When energized, the clutch automatically resets.
Type: Multi-turn
Voltage: 200, 220, 240, 380, 400, 415, 440, 480, 500, 550, 660, 690
Control type: on-off, modulating
Series: intelligent
