HITORK HKP.2-B

Short Description:

The second-generation lightweight rotary electric actuator is a patent-protected electric actuator with integrated rotary output. The original double-display valve position design in the same window makes debugging more convenient. The whole machine is smaller in size and lighter in weight. It can be directly connected to the valve, and can also be connected with a crank arm or a connecting rod to meet the needs of various working conditions. Mostly used in ball valves and butterfly valves.



Product Detail

Product Tags

Product Introduction

Body

The body is hard aluminum alloy, anodized and polyester powder coating, strong corrosion resistance, protection grade is IP67, NEMA4 and 6, and IP68 is available for selection.

Motor

Using a fully enclosed cage motor, it has the characteristics of small size, large torque, and small inertial force. The insulation grade is H grade, and the built-in overheating protection switch can prevent damage to the motor.

Manual structure

The design of the handwheel is safe, reliable, labor-saving and small in size. When the power is off, press the clutch for manual operation. When energized, the clutch automatically resets.

Dryer

It is used to control the temperature, prevent moisture condensation inside the actuator due to temperature and weather changes, and keep the internal electrical components dry.

Torque switch

It can provide overload protection, automatically disconnect the motor power when the valve jams with foreign matter, and more effectively protect the valve and electric actuator from damage. (It has been set before leaving the factory, please do not change the setting at will.)

Self-locking

The precision worm gear mechanism can efficiently transmit large torque, high efficiency, low noise (maximum 50 decibels), long life, self-locking function to prevent reverse rotation, and the transmission part is stable and reliable, and no need to refuel.

Valve position digital display

During the opening or closing process of the actuator, the change of the valve position is displayed in real time on the display in large numbers.

Type: Part-turn

Voltage: 110, 200, 220, 240, 380, 400, 415, 440, 480, 500, 550, 660, 690

Control type: on-off, modulating

Series: intelligent
