LF3015MB Coiled Fiber Laser Cutting Machine

Short Description:

The bed adopts a gantry dual-drive structure, imported screw rods and linear guide rails, stable transmission, high precision, and online rotation of the hobbing, which ensures high efficiency, high quality, time and labor saving of material processing , Improve material utilization.


Product Detail

Product Tags

Product description

Uncoiling Machine
The uncoiler unwinds the roll material, and the width of the loaded coil material is 100-1300mm; the load is 10000kg.

Automatic unloading material
Hobbing type conveying structure, vacuum chuck automatic unloading the unloading the finished product , automatic stacking of finished products, saving labor and improving efficiency.

Product advantage

Machine Advantage
Hign material utilization
One key for any piece of material is processing,programming forms the best material discharging mode,realize the cutting of the net material,and improves the utilization rate of the plate.

Free-form cutting
It can monitor the running range of the beam and cutting parts throughout the process,and quickly feedback to stop the period,Double protection with fixed limits can greatly improve equipment and personal safety and reduce the risk of customer use.

Product Specifications

Machine model LF3015MB
Laser power 1000W/2000W//3000W/4000W(Optional)
Working area 3000mm x 1500mm
Dimensions (5480+8034)*4850*(2650+300)mm
Repeat positioning accuracy ±0.03mm
Maximum speed 120m/min
Max. acceleration 1.5G/2.0G
Voltage and frequency 380V 50Hz/60Hz
