Manufacturer fireproof heat insulation calcium silicate ceramic fiber boards

Short Description:

Ceramic fiber boards are rigid products made from ceramic fiber which are vacuum formed with organic and inorganic binders, with or without mineral fillers. These are manufactured over a wide range of grade densities and harnesses. The board is featured with high temperature stability, low thermal conductivity, even density, and excellent resistance against thermal shock and chemical attack. They can be used as individual component of furnace linings or as hard hot face layer as backup insulation.

Send email to us

Product Detail

Product Tags

Product Advantages

● Low thermal conductivity and low heat storage.
● Excellent thermal stability and thermal shock resistance.
● Structure homogeneity and easy machining.

Typical application

● Industrial furnace wall lining and bricking-upo insulating layer.
● Heat insulation of high temperature and high-heat equipments.
● Combustion chamber of boilers & heaters.
● Heat insulation, fireproof and sound insulation of aerospace, ship building industries.

Technical data

Grade		Standard	Aluminium	Zirconium
Classification Temperature (℃)		1260℃	1350℃	1450℃
Working Temperature (℃)		1100℃	1250℃	1350℃
Density (kg/m³)		280~500
Thermal Conductivity by mean temp. (w/m▪k)		0.085 (w/m▪k)(400℃) 0.132 (w/m▪k)(800℃) 0.180 (w/m▪k)(1000℃)
Compression Strength (Mpa)		0.5
Chemical Composition (%)	Al₂O₃	42~43	52~53	35
	SiO₂	53	46	45
	ZrO₂	-	-	15-17
	Fe₂O₃	≤ 1.2	≤ 0.3	≤ 0.2
	Na₂O + K₂O	≤ 0.5	≤ 0.3	≤ 0.2
Size (mm)		1000×600×10~50mm 1200×1000×10~50mm 1200×500×10~50mm 900×600×10~50mm 600×400×10~50mm

FAQ

1. How many temperature can your board withstand?
Max temperature is 1430C.

2. Can you make OEM?
Yes, we can make any shape and size as your request.

3. What is your board thickness?
Min thickness is 3mm, Max thickness is 75mm.

4. Your certificate?
CE, ISO, MSDS.

5. If the package can be printed our company logo?
Yes, the marks are as your request.

Why choose us?

HIGH QUALITY.EXCELLENT SERVICE.
FAST DELIVERY TIME. Full-automatic production line!
FULL EXPERIENCE. More than ten years producing and selling experience!
Nice after-sale service will be offered and it is a good tradition in our factory.
