New Arrival Durable Tested SUS304 Sturdy Maximum Security Full Height Gate Turnstile for Various Place
About Us
TURBOO Universe has always been committed to the research and development and innovation of new product and the relentless pursuit of the quality of traditional products. In October 2016, the company separately set up Turboo Universe Technology Co., Ltd research and development center, with office area being more than 1500 square and the existing research and development and other related personnel being more than 50 people, at the same time, we have laboratories, test rooms and professional quality centers.
Applying new technologies and new ways to lead the development of the industry, optimizing standard products through research and development, thus we make the products has the highest price in the peer. Besides, we continue to launch new product of line channel gate segments market, establishing technical barriers, and conform to the trend of big data, master large data of sidewalk. The strong strength of research and development makes Turboo has the ability of customers rapid customization, and more uniform and stable product mold standardization, far more than their counterparts in about 5000000 times and more better security.We have won nearly a hundred patents, with the European Union CE certification. 2015 Turboo won the national title of high-tech enterprises.
Product Parameters
| Model NO. | G5385-1 |
| Size | 1630x1500x2300mm |
| Material | 1.5mm +1.0mm 304 stainless steel |
| Pass Width | 650mm |
| Passing Speed | 30-45 person/min |
| Working Voltage | DC 24V |
| Input Voltage | 100V~240V |
| Communication Interface | RS485, Dry contact |
| Reliability of the mechanism | 3 million, no-fault |
| Machine core | Full height turnstile Machine core |
| PCB Board | Full height turnstile drive PCB board |
| Working Environment | ≦90%, No condensation |
| User Environment | Indoor and outdoor |
| Applications | School, hospital, factory, construction site, park, housing estate, prison, stadium, government agency, etc |
| Package Details | Packed into wooden cases, 2200x1680x1270mm, 170kg |
Product Descriptions
Brief introduction
The full height turnstile is a kind of access control equipment designed for places with high class security requirements. It is easy to combine IC access control, ID access control, code reader, fingerprint, face recognition and other identification devices. It realizes the intelligent and efficient management of passage. The turnstile is the best choice for access control of modern building.
Full height turnstile series are fully applicable to places with a large flow of people and high security requirementsplaces, such as school, hospital, factory, construction site, park, housing estate, prison, stadium, government agency and other places.
Upgrade to full automatic full height turnstile is optional.
Function Features
◀Damper buffer device
◀Standard signal input port, can be connected with most of the access control board, fingerprint device and scanner other equipment;
◀The turnstile has automatic reset function, if people swipe the authorized card, but don’t pass through within the settled time, it need to swipe card again for entry;
◀Card-reading Recording function
◀Automatic opening after emergency fire signal input
◀Anti following : prevent illegal passing
◀High light LED indicator, displaying passing status.
◀Normal open can be also controlled via external button or manual key unlock
◀Gate will automatically open when power failure (connect with 24V backup battery or supercapacitor)
Product Descriptions
Full height turnstile drive PCB board
1. Arrow + three-color light interface
2. Memory mode
3. Multiple traffic modes
4. Dry contact / RS485 opening
5. Support fire signal access
6. Support secondary development
·Molding: Die-cast aluminum, special spraying treatment
·Anti-submarine return: 6pcs gears design, unable to return after 60°rotation
·Long life time: Measured 10 million times
·Disadvantages: The pass width is 550mm only, can’t be customized. It’s not easy for pedestrians with large luggage or trolleys to pass.
·Applications: Stadium, Prison, Factory, Construction Site, Community, School, Hospital, Park, etc
Product Dimensions
Product Dimensions
Full height turnstile installed at the entrance and exit of a housing estate in Guangzhou, China
Full height gate installed at the entrance and exit of a housing estate in Guangzhou, China
Single lane full height turnstile installed at the entrance of an activity center in Lagos, Nigeria
