Pusher Rock Drill YT27 YT28 YT29A

Short Description:

YT27 air leg drill is highly efficient and lightweight, suitable for wet drilling down and tilting holes on medium hard or hard (F =8-18) rocks. Drilling hole diameter 34-45 mm, effective depth of drilling up to 5 m. It has the characteristics of strong blowing-cleaning hole function and large torque, which is obviously better than similar products.YT27 air-leg rock drill not only has the advantages of YT23 drilling rig, but also USES flange control valve to produce gas and other functions. It is most suitable for large-scale mining and tunnel drilling operations. It is also widely used for rock drilling tools in railway, water conservancy and national defense stone engineering. It can be used together with FY250 type oil injector and FT160A (or FT160B) type air leg for wet rock drilling of medium and hard rocks, drilling horizontal and inclined gun holes, and unloading air leg can also be installed on a platform car.

  • Model: Yt27
  • N.W.: 27kg
  • Length: 668mm
  • Bit Head Size: R22×108mm
  • Air Consumption: ≤80 L/S
  • Percussive Frequency: ≥36.7 Hz
  • Impact Energy: ≥75.5 J
  • Boreholes Diameter: 34-45mm
  • Piston Diameter: 80mm
  • Piston Stroke: 60mm
  • Working Air Pressure: 0.63 Mpa
  • Working Water Pressure: 0.3 Mpa
  • Drilled Holes Depth: 5m




Product Detail

Product Tags

Air Leg Rock Drill

rock drill bit China supplier

YT27 Air Leg Rock Drill

1.The rock drill is a kind of high efficiency air leg rock drill machinery.
2.It is mainly used for blasting holes and other drilling works in a quarries, railway construction, water conservancy construction and defence project facility.
3.It is suitable for drilling and blasting under various of rocks and any direction angles.
4.Blast hole dia is 34-42mm, drill hole depth is 5m.
5.This machine may match with FT160BD short air leg of FT160BC long air leg.

Quality

100%
compressor rock drill yt29a yt28 yt27 s250 y26 y19a ty24c s82
SPECIFICATIONS for YT series pneumatic rock drilling machine with air leg
Model
YT28
YT27
YT29A
YT24C
TY24
Weight
26kgs
27kgs
26.5kgs
24kgs
24kgs
Length
661mm
668mm
659mm
628mm
678mm
Air pressure
0.4-0.63Mpa
0.4-0.63Mpa
0.4-0.63Mpa
0.4-0.63Mpa
0.4-0.63Mpa
Impact frequency
≧37HZ
≧39HZ
≧39HZ
≧37HZ
≧31HZ
Air consumption
≦81L/s
≦86L/s
≦88L/s
≦80L/s
≦67L/s
Impact energy
≧70J
≧75J
≧78J
≧65J
≧65J
Cylinder*stroke
80mm*60mm
80mm*60mm
82mm*60mm
76mm*60mm
70mm*70mm
Air pipe diameter
25mm
19mm
25mm
25mm
19mm
Shank dimension
22*108mm
22*108mm
22*108mm
22*108mm
22*108mm
Drilling depth
5m
5m
5m
5m
5m
Bit diameter
34-42mm
34-45mm
34-45mm
34-42mm
34-42mm
未标题-2 拷贝

Usage Scenarios

YT27 Air Leg Rock Drill Your good companion

compressor rock drill yt29a yt28 yt27 s250 y26 y19a ty24c

YT27

YT27 air-legged rock drill is a heavy-duty air-legged rock drill with high efficiency low consumption, especially suitable for use in the construction of railroads, highways, hydropower, etc.

compressor rock drill yt29a yt28 yt27 s250 y26 y19a ty24c..

Air Leg Rock Drill

It is also a replacement product for gold, coal and other mining roadway ingress and various rock drilling operations.

compressor rock drill yt29a yt28 yt27 s250 y26 y19a ty24c ....

Shenli Machinery

It is suitable for drilling and blasting under various of rocks and any direction angles.Blast hole dia is 34-42mm, drill hole depth is 5m.

We have made hand-held rock drills

and air-leg rock drills such as y19a, y26

ty24C, yt27, yt28, yt29a, YT29S, S250, etc.

PERFECT QUALITY ASSURANCE
未标题-2 拷贝

Detailed introduction

rock drill yt29a yt28 yt27 s250 y26 y19a ty24c yt29s s82

YT27 Air Leg Rock Drill

Compared with similar products, YT28 YT29 rock drill has the characteristics of high impact power, long service life,easy maintenance, less gas consumption.

YT27
compressor rock drill yt29a yt28 yt27 s250 y26 y19a ty24c.....

YT27 Air Leg Rock Drill

After long-term mining practice, YT28 YT29 rock drill has many advantages. Such as drill faster, light weight and low noice.

Advantages
rock drill yt29a yt28 yt27 s250 y26 y19a ty24c.....

YT27 Air Leg Rock Drill

YT24 YT28 YT29 rock drill is equipped with transparent shell type FY200B oil tank to observe oil level, adjust oil quantity and ensure good lubrication.

Oil feeder

DETAIL VIEW

rock drill yt29a yt28 yt27 s250 y26 y19a ty24c.s82
rock drill yt29a yt28 yt27 s250 y26 y19a ty24c s82
rock drill yt29a yt28 yt27 s250 y26 y19a ty24c... .
rock drill yt29a yt28 yt27 s250 y26 y19a ty24c Air-leg Oil feeder Drill stem Aiguille Bit head

GUARANTEED SAFE & SECURE CHECKOUT

未标题-2 拷贝

· Tracking order traceability.

· On-time delivery guarantee

· 100% qroduct qualification rate

Delivery for :

Express delivery

For the Goods’ Value lower than USD1000 Like 1set or 2 set. We need send it to you by Express.Please tell us your city and postcode for the courier cost.



Time

Delivery by sea: After it was delivered to the seaport . We will tell you the shipping time and arrival time .

Sea Freight

For the Goods’ Value more than USD 1000.Like ≥3 set. We could send it to you by sea. Please tell us your seaport for the Freight cost,In addition, we can also help you consult the shipping price

Air Freight

Delivery by Express to your door (DHL/TNT/Fedex/UPS etc ) or by air to your city airport . We will tell you the Express tracking number .

Freight Forwarding

If you have shipping agent in china. please let your agent contact us.



Services

Deliver it to the warehouse which you have requested . We will tell you logistic or express tracking number .

FAQ：

1. : Are you factory or trade company?
A: We are factory. And we have ourselves trading company.
2: Warranty terms of your machine?
A: 3 months for the core components and technical support according to your needs.
3: Will you provide some spare parts of the machines?
A: Yes, we have most of the spare parts in stock.
4: Which payment term can you accept?
A: 30% T/T in advanced, 70% T/T before the delivery.
5: Can you accept OEM orders?
A: Yes, we have high specialized and rich experienced team, OEM orders are highly welcome.
6: Which trade term can you accept?
A: FOB, CIF, CFR, EXW, CPT, etc.
