The torque load sensor is a precision measuring tool for measuring various torques, speeds and mechanical power. Mainly used in:
1. Detection of output torque and power of rotating power equipment such as electric motors, engines, and internal combustion engines;
2. Detection the torque and power of the fan, water pump, gear box, and torque wrench;
3. Detection of torque and power in railway locomotives, automobiles, tractors, airplanes, ships, and mining machinery;
4. It can be used for the detection of torque and power in the sewage treatment system;
5. It can be used to manufacture viscometer;
6. It can be used in process industry and process industry.
Technical Parameter (Range:0.01~2N.m )
Torque accuracy | <±0.5 %F-S、<±0.2 %F.S、<+0.1% F·S(Optional) |
Frequency response | 100μs |
Nolinear | <±0.2% F.S |
Repeatability | <0.1%F. S |
Output resistance | 350Ω±1Ω、700Ω±3Ω、1000Ω±5Ω(Optional) |
Return difference | <0.1 %F S |
zero drift | <0.2 %F. S |
Zero temperature drift | <0.2 %F. S /10℃ |
Insulation resistance | >500Ω |
The static overload | 120% 150% 200% (Optional) |
Environment temperature | -20 ~ 50℃ |
Storage temperature | -20 ~ 70℃ |
Total current consumption | < 200mA |
Frequency signal output | 5KHZ-15KHZ |
Rated torque | 10KHZ±5KHZ (Positive and negative bidirectional measurement value) |
Supply voltage | ±15VDC、24VDC (Optional) |
Output signal | 5KHz-15KHz、0-20mA、4-20mA、0-5V、0-10V、1-5V、0±5V、0-±10V(Optional) |
