Self Adhesive Membrane Liner for Building Waterproof Lining Project
PEEL&STICK(SELF -ADHESIVE
Peel&Stick (self-adhesive) is a new type of installation solution. Its biggest advantage is that no welding is required during installation, only self-adhesive layer bonding is required. Convenient and practical, high efficiency, saving labor costs. It is widely used in roof waterproofing, building basement waterproofing, corner waterproofing, water leakage repairing and other places. We provide TPO self-adhesive geomembranes, PVC self-adhesive geomembranes and other types of self-adhesive geomembranes. Its excellent quality and exquisite craftsmanship will escort your projects.
| TESTED PROPERTY | TEST METHOD | UNIT ENGLISH METRIC |
VALUE ENGLISH(METRIC |
||||
| 20PV | 30PV | 40PV | 50PV | 60PV | |||
| Thickness | ADTM D 5199 | mil(mm) | 20±1（0.51±0.03） | 30±1.5（0.76±0.04） | 40±2（1.02±0.05） | 50±2.5（1.27±0.06） | 60±3（1.52±0.08） |
| Tensile properties: Strength at break Elongation Modulus @ 100% |
ASTM D 882 Min | lbs/in(kN/m) % lbs/in(kN/m) |
48(8.4） 360 21（3.7） |
73(12.8) 380 32（5.6） |
97(17) 430 40（7.0） |
116(20.3) 430 50（8.8） |
137(24.0) 450 60（10.5） |
| Tear Strength | ASTM D 1004 min | Ib(N) | 6(27) | 8(35) | 10(44) | 13(58) | 15(67) |
| Dimensional Stability | ASTM D1204 Max Chg | % | 4 | 3 | 3 | 3 | 3 |
| Low temperature impact | ASTM D 1790 Pass | °F（°C） | -15（-26） | -20（-29） | -20（-29） | -20（-29） | -20（-29） |
| INDEX PROPERITIES | |||||||
| Specific Gravity | ASTM D 792 Typical | g/cc | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
| Water Extraction %loss(Max) | ASTM D 1239 Max Loss |
% | 0.15 | 0.15 | 0.2 | 0.2 | 0.2 |
| Average Plasticizer Molecular Weight | ASTM D 2124 | 400 | 400 | 400 | 400 | 400 | |
| Votatility Loss % loss(Max) | ASTM D 1203 Max Loss | % | 0.9 | 0.7 | 0.5 | 0.5 | 0.5 |
| Soil Burial Break strength Elongation Modulus @ 100% |
G160 max chg | % % % |
5 20 20 |
5 20 20 |
5 20 20 |
5 20 20 |
5 20 20 |
| Hydrostatic Resistance | ASTM D 751 min | psi(kpa) | 68(470) | 100(690) | 120(830) | 150(1030) | 180（1240） |
| SEAM STRENGTH | |||||||
| Shear Strength | ASTM 882 D min | lbs/in(kN/m) | 38.4(6.7) | 58.4(10) | 77.6(14) | 96(17) | 116(20) |
| Peel Strength | ASTM 882 D min | lbs/in(kN/m) | 12.5(2.2) | 15(2.6) | 15(2.6) | 15(2.6) | 15(2.6) |
| This data is provided for informational purposes only. Trump Eco makes no warranties as to the suitability or the fitness for a specific use or merchantability of the products referred to, no guarantee of satisfactory results from reliance upon contained information or recommendations and disclaims all liability from resulting loss or damage. This information is subject to change without notice, | |||||||
APPLICATIONS
- Industrial and civil building waterproofing.
- Geosynthetic liner for swimming pool, channels, irrigation system.
- Suitable for projects requiring high performance on durability, anti-corrosion and distortion prevention.
Why Choose Us
- Competitive pricing.
- Supplying waterproofing solutions since 1983.
- We concentrate on service quality and professional skills
- Manufacturing geosynthetics & macromolecule waterproofing materials since 2001.
- 24/7 service available.
- Free sample.
- Online factory check.
- On time delivery.
- ASTM CE CRI standard.
- OEM order is acceptable.
- Professional R&D team.
Features
- Strong tensile strength, high elongation, good dimensional stability after heat treatment.
- Excellent flexibility at low temperature, excellent resistance to the low and high temperature.
- Excellent resistance to impact and perforation.
- Excellent resistance to chemical etching.
- Fireproof : the membrane extinguish immediately after away from the fire source.
- Strong adhesion to the substrate: easy and fast construction without pollution.
- Excellent resistance to the aging, long service life.
- Service life: more than 20 years as roof waterproof material, more than 50years if used in underground waterproof .
- Repair project: Repair the damage place only and reduce the repair cost.
- Various colors are available.
