Single Chain Window Opener D-QDL02

Application Rang

◆The utility model can be used for inner window opening, inner opening hanging window, inner opening and lower hanging window;

◆ Can be used for intelligent single control, and D-KZ04 controller in conjunction with the use of;

◆ It can be used in intelligent ventilation system and fire smoke evacuation system;

◆Up to 2 window opener can work synchronously, and cooperate with D-ZLTB-2 synchronizer;

◆Window system for wooden, PVC and aluminium alloy materials;

◆Window sash or window frame installation.

Product Feature

◆The shell is made of high strength aluminum alloy;

◆The surface treatment of the shell is fluorocarbon spraying;

◆The chain is made of high strength 304 stainless steel;

◆Life is more than 30000 times of steel;

◆Strong corrosion resistance and large pulling force；

◆Good sealing performance.

Technical Parameters

Matters Need Attention

◆When choosing a window opener, snow load and wind load should be taken into account; ◆The North needs to be frozen.Remote Control Handset

Product name: remote controller

Product parameters: Working power supply 7AAA 1.5V remote control distance 20m

Features

◆The remote control has a remote control transmitter and a remote control receiver

Two parts

◆The optional remote control for the Yale power window system can be found in

Use within a radius of 20 meters;

◆The remote control uses electromagnetic wave frequency modulation to transmit and receive the original

It is not affected by the occlusion of objects;

◆One remote control transmitter can control one or more

Remote control receiver of the same frequency.

Wind and Rain Sensor

Product name: Wind and rain controller Product Code: D-GY02 Product parameters: Working voltage 12VDC Working temperature -20～+85℃ Features ◆Low noise and stable operation, flexible and changeable installation methods; ◆The shell material is resistant to ultraviolet radiation and conforms to the outdoor use standard allow; ◆Wind feeling part adopts stainless steel double bearing structure, sensitivity high; ◆The knob scale on the shell adopts laser laser, which is clear and durable Long; ◆The wind and rain intensity adjustment has high precision and sensitive response; ◆The wind and rain sensor adopts the intelligent control of the single-chip microcomputer, It not only ensures the rapid response of the wind, but also takes into account the light and rain The sense of stability and reliability.

Touch-Screen Control Panel

Product model: D-KZ04-1A,

D-KZ04-2A

Product parameters:

Input voltage: 220V AC 50HZ

Output voltage: 24V DC

Dimensions: 86×86×33mm

Working environment: working temperature -40～+85℃

Working humidity ≤95%

Touch life: 100000 times

Features

◆The touch screen controller has good water resistance, and the panel is moist and leak-free

Electricity, safety guarantee;

◆High-grade tempered glass panel, the surface is easy to clean and not easy to scratch

Flower, highly sensitive touch screen;

◆LED night light design, not afraid of the dark;

◆Fine edging, beveled edge design, never hurt your hands

Smoke sensor

Product name: Smoke sensor

Product Code: D-GY01

Product parameters:

◆Working voltage: 12V DC

◆Working environment: temperature: -10～50℃; relative humidity ≤95%RH (no condensation)

◆Working current: static: ≤10uA; alarm: ≤20mA

◆Alarm mode: sound and light alarm

◆Monitoring area: 20-40 square meters

◆Dimensions: Φ107*35mm

◆Smoke sensitivity: in line with UL’s 217 standard

◆Executive standard: GB4715-1993

Features

◆Manual test;

◆Automatic reset;

◆Adopt special microprocessor control;

◆Strong adaptability to the environment;

◆Dust-proof, insect-proof, anti-white light interference;

◆Using SMT process manufacturing, strong stability

Fire Control Box

Product name: Fire-fighting electrical control device

Product Code: D-KZG01

Product parameters:

◆Working voltage: 220V AC50HZ

◆Maximum output power: 250W

◆Static power consumption: 7W

◆Environmental temperature: -10℃～+75℃

◆Output control capability: 1 interlock output

◆Maximum control current: 10A

◆Output voltage: 24V DC

Features

◆Connect the wind and rain controller, smoke detector, emergency fire button and other detection equipment;

◆ Linked with fire fighting signal, when a fire occurs, the window can be opened to exhaust smoke in time, normal

In this case, the switch window can be manually controlled;

◆The system has a backup power supply, and the window can be opened to exhaust smoke when the power is disconnected;

◆The window opening time can be adjusted according to the specific window opening situation.

Application Occasions

1. The installation position of the window is high or too far, and the window that can not be reached by manpower alone, such as: high-rise building window.

2. The window is too heavy, it is laborious to open or close, and the manual switch is inconvenient to use.

3. The floors have fire-fighting smoke exhaust windows that require fire-fighting linkage ventilation.

4. Windows that require weather switch windows, such as windows that need to be closed automatically when it rains in a warehouse.

5. Windows that require constant temperature in the room, such as windows in vegetable or flower greenhouses.

6. There are requirements for the indoor temperature. If the temperature is too high, the window must be opened automatically, such as the window of the communication room.

7. Working in windows that have strict requirements for indoor air index and need to ventilate and ventilate the environment in time.

8. The window needs to be closed and sealed tightly, such as rainproof skylights need to be closed tightly.

9. Green, smart, energy-saving windows for modern high-rise buildings, such as curtain wall windows.

10. Building automatic control, smart home control, etc.

Specific use cases include: homes, large stadiums, waiting (airport) halls, shopping malls, hotels, schools, hospitals, public entertainment venues, workshops, warehouses, office buildings, nursing homes, etc.
