As a professional slewing drive manufacturer,WE company can supply standard model slewing drive size from 3 inch to 25 inch,including SE series & heavy type WEA series & dual worm slewing drive.We also can make non-standard model slewing drive according to the customer’s requirements.
We also can supply hydraulic motor and DC motor to match our slewing drive.Below are our standard model slewing drives technical information for reference:
DIMENSIONS PARAMETER | |||||||||||||||||
Model | Dimensions | Installation Dimensions | Mounting Hole Date | ||||||||||||||
L1 | L2 | L3 | H2 | D0 | D2 | D3 | D4 | D5 | n1 | M1 | T1 | T2 | n2 | M2 | T3 | T4 | |
mm | Inner Ring | Outer Ring | |||||||||||||||
SE3 | 190 | 160.5 | 80 | 109 | 152 | 100 | no | no | 100 | 6 | M10 | 17 | 32 | 6 | M10 | 22 | no |
SE5 | 219.2 | 170.5 | 93.7 | 80 | 183 | 70 | 50 | 103.5 | 135 | (8-1) | M10 | 20 | 42 | 6 | M10 | 20 | 39 |
SE7 | 295.7 | 186 | 132.7 | 83.8 | 258 | 120.6 | 98 | 163 | 203.2 | 10 | M12 | 25 | 47 | 8 | M12 | 25 | 43.4 |
SE9 | 410.5 | 321.7 | 174.2 | 107.9 | 345 | 175 | 146 | 222.5 | 270 | (16-1) | M16 | 30 | 65.9 | 16 | M16 | 30 | 52 |
SE12 | 499.5 | 339.5 | 220 | 110.4 | 431 | 259 | 229 | 314.3 | 358 | (20-1) | M16 | 30 | 69.4 | 18 | M16 | 30 | 51 |
SE14 | 529.9 | 337.5 | 237.6 | 111 | 456.5 | 295 | 265 | 342.5 | 390 | (24-1) | M16 | 30 | 69 | 18 | M16 | 30 | 52 |
SE17 | 621.8 | 385.2 | 282.6 | 126 | 550.5 | 365.1 | 324 | 422.1 | 479.4 | 20 | M16 | 32 | 79 | 20 | M16 | 32 | 55 |
SE21 | 750.4 | 475 | 345 | 140 | 667.7 | 466.7 | 431.8 | 525.5 | 584.2 | (36-1) | M20 | 40 | 85 | 36 | M20 | 40 | no |
SE25 | 862.8 | 469 | 401.8 | 130 | 792 | 565 | 512 | 620 | 675 | (36-1) | M20 | 40 | 87 | 36 | M20 | 40 | no |
PERFORMANCE PARAMETERS | |||||||||||||||||
Model | (MAX)kN.m Output Torque |
(MAX)kN.m Tilting Moment Torque |
KN Static Axial Load |
kN Static Radial Load |
(MAX)kN.m Dynamic Axial Load |
(MAX)kN.m Dynamic Radial Load |
(MAX)kN.m Holding Torque |
Gear Radio | Tracking Precision | Self-locking Gears | kg Weight |
||||||
SE3 | 0.4 | 1.1 | 30 | 16.6 | 9.6 | 8.4 | 2 | 62:1 | ≤0.20° | Yes | 14 kg | ||||||
SE5 | 0.6 | 3 | 45 | 22 | 14.4 | 11.1 | 5.5 | 62:1 | ≤0.20° | Yes | 13 kg | ||||||
SE7 | 1.5 | 13.5 | 133 | 53 | 32 | 28 | 10.4 | 73:1 | ≤0.20° | Yes | 23 kg | ||||||
SE9 | 6.5 | 33.9 | 338 | 135 | 81 | 71 | 38.7 | 61:1 | ≤0.20° | Yes | 50 kg | ||||||
SE12 | 7.5 | 54.3 | 475 | 190 | 114 | 100 | 43 | 78:1 | ≤0.20° | Yes | 65 kg | ||||||
SE14 | 8 | 67.8 | 555 | 222 | 133 | 117 | 48 | 85:1 | ≤0.20° | Yes | 70 kg | ||||||
SE17 | 10 | 135.6 | 970 | 390 | 235 | 205 | 72.3 | 102:1 | ≤0.15° | Yes | 105 kg | ||||||
SE21 | 15 | 203 | 1598 | 640 | 385 | 335 | 105.8 | 125:1 | ≤0.15° | Yes | 180 kg | ||||||
SE25 | 18 | 271 | 2360 | 945 | 590 | 470 | 158.3 | 150:1 | ≤0.15° | Yes | 218 kg |
Below are our hydraulic motor technical parameters,you can choose the right one according to your requirements,most type we have stock in our warehouse.
Our advantages:
1.We have professional product design and load calcalation capacity;
2.Our products all are made with high-quality materials (50Mn & 42CrMo & C45 & 2Cr13 ) to ensure the mechanical properties
3.We have total quality management from material, production processes to finished product;
4.Our company continuous improvement of comprehensive strength, 2 factories under operation and 1 factory under construction with over 230 employees, providing slewing bearings 6000sets/month, slewing drives 1000sets/month.Most slewing drive we have stock in our warehouse.
5.Strong technical and R & D capabilities with an experienced technical team and cooperation with China University of Mining and Technology, Northwestern Polytechnical University and Tsinghua University.
6.Rich export experience, products are exported to more than 60 countries and regions.
7.Professional supplier of marine slewing bearing,we can supply CCS certificate.
Since its establishment, our factory has been developing first world class products with adhering the principle
of quality first. Our products have gained excellent reputation in the industry and valuabletrusty among new and old customers..
