Tube Screw Conveyor
Product Description for GX tube screw conveyor
GX tube Screw Conveyor also known as auger conveyor, and spiral conveyor.GX tube Screw conveyor is used in many industries, such as building materials, chemical engineering, coal, grain and oil, fodder. It is suitable for horizontal or inclined conveyor powdery, granulous and small block material, such as grain, dinas, coal, flour, cement, chemical fertilizer and so on. It cant convey material which is easy to metamorphic, sticky, agglomeration; Using temperature of environment is -20~50℃,conveying material temperature is ≤200℃.
Classification
Features
1. Good sealed, large capacity, long conveying distance.
2. Good seal performance, good transportation efficiency!
3. Flexible technological arrangement, easy to be installed , dismantled and moved, safe operation!
4. Compact structure, small cross section, light weight!
5. LS screw conveyor can mixing, heating and cooling in the process of conveying.
GX Tube Screw Conveyor Suitable for
1.Food Processing 2.Pharmaceutical
3.Powder and energy 4.Petrochemical
5.Chemicals 6.Mining and minerals
7.Feed processing 8.Plastic
Parameter Sheet
|
Model |
GX-100 |
GX-160 |
GX-200 |
GX-250 |
GX-315 |
GX-400 |
GX-500 |
|
Screw Diameter (mm) |
100 |
160 |
200 |
250 |
315 |
400 |
500 |
|
Screw Pith (mm) |
100 |
160 |
200 |
250 |
315 |
355 |
400 |
|
Speed (r/min) |
140 |
112 |
100 |
90 |
80 |
71 |
63 |
|
Capacity (m³) |
2.2 |
8 |
14 |
24 |
34 |
64 |
100 |
How to confirming the model
1).The capacity(Tons/Hour) that you require?
2).The conveying distance or the conveyor length?
3).The conveying angle?
4).Whats the material to be convey?
5).Other special requirement,like hopper,wheels etc.
