Ag Panel Roll Former

Ag panel is one of the most popular ,high value metal roof and siding panels in the construction industry.AG panel is a very durable roofing system,with 36inch cover width.Manufactured in 29gauge,26gauge,24gauge.

Our AG panel roll former is designed to make ag panels,people also call it tuff rib panels. is one of the leading manufacturer of ag panel roll former in China.And specialized in designing portable roll forming machine,ag  panel roll former,pbr panel roll former.

Summary of Advantage panel roll forming machine

1.Suitable material:galvanized steel,pre painted galvanized steel

2.Material Thickness:29gauge,24 gauge 26,gauge

3.Main power of roll forming machine:7.5kw

4.Output width:36inch

5.power supply:208v,60hz,3p

Main Components of ag  panel machine

1.Manual decoiler

2.Manual Pre-cutting

3.Material guiding system

4.Roll Forming System

5.Hydraulic Guillotine

6.Control System

7.Run out Table

Working Flow of machine

manual decoiler-feeding-roll forming-hydraulic cutting-run out table

Technical Data of panel roll former

Decoiler

Decoiler Type:  manual or auto for your opition

Capacity of Decoiler:7Tons

Roll Forming Part with material guiding

Diameter of shaft:75mm

Material of shaft:45#Steel with quenched heat treatment

Roller Material:45# with hard chrome coating and quench heat treatment

Forming Speed:17-20m/min

Transmission:by chain

Structure of roll forming machine:350/400H Beam

Hydraulic cutting Device:

Cutting method:hydraulic stop cutting,electric cutting,non stop servo motor cutting

Power Of Cutting Motor:4kw,55kw for your opition

Control system:

PLC System:Panasonic,Delta

Length controller:Encoder Omron

Inverter:Panasonic,YASKAWA

Out Put table:

Length of table:3meters
